Lukas Theisgen

Process Model for the Systematic Design of Modular Surgical Robots


Front	Back

ISBN:

978-3-8440-9595-1

Series:

Aachener Beiträge zur Medizintechnik
Herausgeber: Univ.-Prof. Dr.-Ing. Dr. med. Steffen Leonhardt, Univ.-Prof. Dr.-Ing. Klaus Radermacher and Univ.-Prof. Dr. med. Dipl.-Ing. Thomas Schmitz-Rode
Aachen

Volume:

Keywords:

Robot-Assisted Surgery; Surgical Robotics; Modular Design; MBSE; Medical Robot; DfX; Surgical Safety; Risk Management

Type of publication:

Thesis

Language:

English

Pages:

190 pages

Figures:

75 figures

Weight:

259 g

Format:

21 x 14,8 cm

Binding:

Paperback

Price:

58,80 € / 73,60 SFr

Published:

August 2024

Buy:

Recommendation:

You want to recommend this title?

Review copy:

Here you can order a review copy.

Link:

You want to link this page? Click here.

Export citations:

Text
BibTex
RIS

Abstract:

The potential of robot-assisted surgery is huge in terms of surgical outcome, safety, ergonomics, and cost efficiency. Yet, most commercial robots and research projects focus on optimizing certain aspects while unwittingly worsening others. The manufacturing industry, on the other hand, uses systematic modularization to harmonize conflicting goals during product development. A prerequisite for the adaptation to surgical robotics is the adequate consideration of intraoperative hazards, deficits of current robots, and the safety and usability of emerging intraoperative interfaces.

Here, a process model was developed for the systematic modularization of surgical robots with integrated risk estimation (MORE), and recommendations for the design of intraoperative interfaces. Key results are the modularization method for surgical robots, the Point-of-View (PoV) framework, the Catalogue of Hazards (CoH), the Reference Architecture Model (RAM), and the Design-for-Intraoperative-Assembly (DfIA) checklist.

The modularization method uses 11 reference functions to suit various use case scenarios and 59 module drivers as quality criteria based on the analysis of 15 surgical robots and the feedback from 51 experts. The PoV framework expands the search area for hazards suggesting 7 predefined perspectives while the CoH provides a database to complement future and systematic risk analyses. PoV and CoH were initially tested on the example of robotically assisted laminectomy, which led to the identification of 133 hazards and 108 hazardous situations. The RAM approach provides structural and procedural rules between functional and physical system elements based on SysML. The DfIA checklist contains 44 control questions of which 18 refer to hygiene and 26 to the assembly process.
